Double girder bridge crane

LH model double beam bridge crane

Capacity: 3~50ton
Span: 7.5~35m
Lifting height: 6~18m
Duty class: A3/A4
Product description: LH model double beam bridge crane with double rail electric hoist
INQUIRY

LH model double beam bridge crane is traveling on fixed support, The frame adopts box-type welding mechanism, and it used together with CD1 or MD1 model wire rope electric hoist as a complete set, It is an mid-duty class crane, the capacity from 3ton to 50ton. The span is 7.5-35m. working grade is A3~A4. Working temperature is -20 to +45 centigrade.

This bridge crane is widely used in plants, warehouses, material stocks to lift goods. It is prohibited to use the equipmenmt in the combustible, explosive to corrosives environment.

The control models are pendant pushbutton control, wireless remote control and cabin control for choice.
